| Specification | Unit | SSP 30 | SSP 50 | SSP 75 | SSP 100 | SSP 150 | SSP 200 |
|---|---|---|---|---|---|---|---|
| Main Supply Cable Size (Alum 2.5 core) | mm² | 30 | 50 | 80 | 100 | 120 | 140 |
| Throat Clearance | mm | 200 | 250 | 250 | 250 | 300 | 300 |
| Electrode Stroke | mm | 75 | 75 | 75 | 100 | 100 | 100 |
| Force/Cyl NB (@ 5.6Kg/cm² Air Pressure) | kgf/mm | 450/100 | 450/100 | 450/100 | 450/100 | 1000/150 | 1000/150 |
| Main Disconnect Switch | Amps | 75 | 100 | 150 | 200 | 375 | 500 |
